R56-T5820-0TS Leviton Tamper Resistant Residential Grade Duplex Outlet
Residential grade tamper resistant thermoplastic duplex grounding receptacle. Shutter mechanism inside the receptacle blocks access to the contacts unless a 2-prong plug is inserted, ensuring objects such as hairpins and keys will be locked out. Features a narrow body, side wired, and large head terminal screws that accept up to
No. 10 copper wire. Triple wire power contacts for maximum conductivity and plug retention, captive mounting screws for fast installation. Convenient washer-type break-off plaster ears for best flush alignment and break-off tabs for easy 2-circuit conversion. Includes heavy-gauge rust-resistant steel mounting strap. Limited 2-year warranty.
No. R56-T5820-0TS: Color: Light Almond, Amperage: 20, Grade: Residential, NEMA Configuration: 5-20R, Voltage: 125, Number Of Poles: 2, Number Of Wires: 3, Certification: UL Listed, Pkg Qty: 1, Package Type: Box
No. R51-T5820-0IS: Color: Ivory, Amperage: 20, Grade: Residential, NEMA Configuration: 5-20R, Voltage: 125, Number Of Poles: 2, Number Of Wires: 3, Certification: UL Listed, Pkg Qty: 1, Package Type: Box
No. S02-T5820-0WS: Color: White, Amperage: 20, Grade: Residential, NEMA Configuration: 5-20R, Voltage: 125, Number Of Poles: 2, Number Of Wires: 3, Certification: UL Listed, Pkg Qty: 1, Package Type: Box
Sold as Unit of Measure: EACH
Minimum/Multiple Order Quantity: 1
